Incucell

Natural, precise – laboratory incubator

55-liter chamber volume

Working temperature of from +5°C above ambient up to 100°C

Noiseless operation and fine air flow in the chamber

High operation comfort, precise temperature regulation and short times of temperature recovery in the chamber after the door opening

High-quality and safe drying, heating and tempering of common laboratory materials in laboratories and industry; suitable for safe processing of microbiological cultures

Model with a Fuzzy logic microprocessor control system; control elements situated on a foil keyboard, process information indicated on a LED display

Wide range of optional equipment and accessories

Output for a printer or PC connection

Validation possibility (IQ , OQ)

Interior of stainless steel material No. 1.4301

Technical data
Inner space	volume	l	22	55	111	222	404	707
width	mm	240	400	540	540	540	940
depth	mm	350 / 320	370	370	520	520	520
height	mm	300	350	530	760	1410	1410
External dimensions (including door, handle, legs N or casters K)	width	max. mm	406	620	760	760	760	1160
depth	max. mm	560	640	640	790	790	790
height	max. mm	610N	680N	860N	1095N	1910K	1910K
ventilation neck diameter - internal / external	mm	52/49	52/49	52/49	52/49	52/49	52/49
Package – basic package	width	approx mm	500	700	830	860	830	1230
depth	approx mm	720	730	730	860	860	860
height (including palette)	approx mm	810	875	1060	1260	2085	2085
Package - case	width	approx mm	720	780	810	920	910	1335
depth	approx mm	780	800	910	960	970	1060
height (including palette)	approx mm	835	900	1085	1310	2123	2163
Package – wooden crate	width	approx mm	-	780	900	900	910	1310
depth	approx mm	-	800	800	940	940	940
height (including palette)	approx mm	-	870	1090	1270	2120	2120
Trays / shelves	maximal number	pc	4	4	7	10	19	19
standard equipment	pc	2	2	2	2	2	2
minimal distance between trays/shelves	mm	60	70	70	70	70	70
usable area	mm	185×265	380×335	520×335	520×485	520×485	920×485
Maximal allowed loading of trays *)	per 1 tray	kg	10	20	20	30	30	50
per 1 shelf	kg	10	20	20	30	30	20
inside the device - in total	kg	25	50	50	70	100	130
Number of external metal door	pc	1	1	1	1	1	2
Weight	net	approx kg	31	55	75	100	150	215
gross (cartoon)	approx kg	36	66	87	116	175	240
Electric data – mains 50/60 Hz	max. input	kW	0,24/0,96	0,3/0,7	0,3/0,7	0,5/0,7	0,9/1,3	0,9/1,3
stand by input	W	5	5	5	5	5	5
current for voltage **)	A	1,1/4,2	1,3/3	1,3/3	2/3	3,9/5,6	3,9/5,6
V	230	230	230	230	230	230
current for voltage **)	A	2,2/8,4	2,6/6	2,6/6	4/6	7,8/11,3	7,8/11,3
V	115	115	115	115	115	115
Degree of coverage	IP20	IP20	IP20	IP20	IP20	IP20
Temperature data
Operation temperature	from 5°C/10°C ***) above ambient temperature	to°C	100	100	100	100	100	100
Variations from operation temperature with closed ﬂap and door (DIN 12 880 part 2)	space	% temperature	1,1/0,4	0,5/ 0,3	0,5/ 0,3	1/ 0,3	1/ 0,8	1,5/ 1,5
time	±°C	0,4/0,1	0,2	0,2	0,2	0,2	0,2
Time to reach temperature of 37°C with closed ﬂap and voltage 230 V	min	70/8	49/41	57/51	79/66	41/38	59/51
Number of air exchanges at 37°C	h-1	4/45	5/45	5/49	5/24	5/18	5/12
Heat losses	at 37°C	W	20/70	30/80	45/95	45/95	65/115	85/135
