VM-54 được thiết kế cho các phép đo rung khác nhau với gia tốc ba trục. Các thẻ chương trình tùy chọn (VX-54 series) giúp bạn thực hiện các phép đo rung liên quan đến con người.
Thông số kỹ thuật
Applicable standards : ISO 6954: 2000
Input : Accelerometer (tri-axial) PV-83CW, or Accelerometer PV-57A (option)
Measurement : 1 to 80 Hz(Up to 1 kHz with flat characteristics,
frequency range when using PV-57A)
Frequency weighting : Wm (ISO 2631-2: 2003), bandwidth limiting
Measurement modes : Acceleration, velocity
Measurement range :
【With PV-83CW】Acceleration (mm/s2): 30, 100, 300, 1000, 3 000, 10 000 Velocity (mm/s):1, 3, 10, 30, 100, 300
【With PV-57A】Acceleration (m/s2): 0.3, 1, 3, 10, 30, 100, 300, 1000 Velocity (mm/s): 10, 30, 100, 300, 1000, 3 000
Processing functions : RMS, max (MTVV), min
Measurement time settings : 10 sec, 1 min, 2 min, 10 min
Display : LCD x 2 (main and sub)
Data store function: Manual store (up to 400 000 data can be stored on VX-54WS [128 MB CFCard])
Recording media : CompactFlash memory card
Interface : For dedicated printer only (allows measurement data printout on dedicated printer)
Output connectors : Connectors for 3 axis signals (AC)
Ambient conditions : -10 to +50 oC, max. 90 % RH
Power supply : Four IEC R14 (size "C") batteries,16 hours continuous operation with alkaline batteries
Dimensions and weight : Approx. 56 (H) x 200 (W) x 175 (D) mm;approx. 1 kg (including batteries)
Supplied accessories : Accelerometer (tri-axial) PV-83CW. Connection Cable EC-54 (1.5 m) Soft protection case
